TOMEI POWERED INC. ONLINE CATALOGUE

Ti SPORTS チタニウムマフラー GR86(ZN8)/BRZ(ZD8)

エキゾースト関連

GR86・BRZ用MT/ATに対応する唯一無二の保安基準適合マフラー

Ti SPORTSマフラーシリーズは競技専用マフラーのこれまでの開発実績から、サーキットでのスポーツ走行を行うためにふさわしい排気効率や軽量化技術を再度練り直し、街乗りでの音量を抑え環境に配慮した保安基準適合マフラーです。
抜けが良く、心地よいフルチタンサウンドをぜひ、あなたの愛車で体感してください。

PRODUCT INFO

適用 品番 定価 備考
GR86(ZN8)
BRZ(ZD8)
442004 ¥398,000 (税込 ¥437,800) ・保安基準適合
・JQR認証済み

FEATURE / SPEC

キット構成KIT CONTENTS

  • メインパイプAMAIN PIPE A
  • メインパイプBMAIN PIPE B
  • メインパイプCMAIN PIPE C
  • M8 ボルトM8 BOLT
  • M8 ナットM8 NUT
  • M8 プレートワッシャーM8 PLATE WASHER
  • クランプ用プレートCLAMPING PLATE
  • ジョイントバンドクランプJOINT BAND CLAMP
  • アルミテープALUMINUM TAPE
  • マウントステーMOUNTING BRACKET
  • M6 ボルトM6 BOLT
  • SPEC
    フルチタンマフラーならではの迫力ある、抜けの良い排気音。その音量は環境に配慮し、厳しい排気音量規制をクリアしJQR認証を得ています。


    サブサイレンサー、メインサイレンサー内径は絞りのない設計とし、スポーツ走行に最適な排気効率を追求。
    ストレート構造でシングル出し、そしてチタンマフラーならではの軽量化を果たした保安基準適合マフラーとして理想のパフォーマンスを実現します。
    A powerful, iconic, and free-flowing exhaust note unique to a full titanium exhaust muffler.
    Reduced sound level for everyday driving, as well as to meet increasingly strict noise regulations even on today’s tracks.
    Optimized flow achieved by the straight-through, non-restricted inner diameter structure.
    Significant weight reduction from the single out design made by high quality titanium delivers next level of performance on the street.
    Ti SPORTS STD (M/T)
    材質MATERIAL チタニウムTITANIUM スチールIRON
    メインパイプ径MAIN PIPE DIAMETER Φ70 φ53-φ60-φ60W
    サブサイレンサー径SUB SILENCER DIAMETER 異形VARIANT 異形VARIANT
    メインサイレンサー径MAIN SILENCER DIAMETER Φ130 オーバルOVAL
    メインパイプ厚MAIN PIPE THICKNESS 1mm 1.5mm
    出口径EXIT DIAMETER Φ112 φ110二重管W110mm dual
    フランジ厚FLANGE THICKNESS プレスフランジ t=2.0mmPRESSED FLANGE t=2.0mm 2.0mm
    近接排気騒音dB:@ 3,500RPM
    MT
    AT
    85.4dB
    95dB 94dB
    加速走行騒音dB:@ Acceleration from 50km/h 82dB 82dB  –
    重量WEIGHT 8.7kg 16.3kg
    JQR認証の基準をクリア Meets the street regulation
    型押しのTOMEIロゴと事前認証制度適合の証であるJQR認証プレートをサイレンサー下側に配し、Ti SPORTSマフラーの品質を視覚的にアピール。また、レゾネーターを採用することで上質な音質と排気効率を落とすことなく音量を抑制し、スポーツ走行だけでなく、公道で使用するにあたっても安心の保安基準適合タイプです。 Pressed TOMEI logo on the main muffler.
    The JQR certificate plate also on the muffler is to prove it’s certified and meets the Japan’s street regulation.
    The external resonator reduces the noise level while keeping the straight-flow structure to suit wide usage from sport to everyday driving on the street.
    スタイルSTYLE

    大口径テールエンドBig mouth end tip

    砲弾タイプのメインサイレンサーを採用。
    大口径テールエンドはバフ処理と鮮やかなチタンブルーを施し、TOMEIロゴがデザインされています。
    Aggressive and dynamic appearance of the big mouth tail end features a buffed finish and a vivid titanium blue color, with the TOMEI logo incorporated into the design.




    関連製品RELATED PRODUCT

    バンパーガーニッシュBUMPER GARNISH

    Ti SPORTS TITANIUM MUFFLER for GR86(ZN8)/BRZ(ZD8)

    EXHAUST SYSTEM

    A titanium muffler compatible with the MT/AT of the GR86 and BRZ.

    Ti SPORTS is a street-legal exhaust muffler brand produced by TOMEI, built with over 50 years of experience in producing racing exhaust systems.
    Reduced sound level to meet the street regulation while delivering lightweight, high flow performance and the iconic titanium sound.
    Fits both AT and MT GR86/BRZ, designed for those seeking racing-inspired performance on the street.

    PRODUCT INFO

    APPLICATION P/N JPY NOTES
    GR86(ZN8)
    BRZ(ZD8)
    442004 ¥398,000 Street-legal certified

    FEATURE / SPEC

    キット構成KIT CONTENTS

  • メインパイプAMAIN PIPE A
  • メインパイプBMAIN PIPE B
  • メインパイプCMAIN PIPE C
  • M8 ボルトM8 BOLT
  • M8 ナットM8 NUT
  • M8 プレートワッシャーM8 PLATE WASHER
  • クランプ用プレートCLAMPING PLATE
  • ジョイントバンドクランプJOINT BAND CLAMP
  • アルミテープALUMINUM TAPE
  • マウントステーMOUNTING BRACKET
  • M6 ボルトM6 BOLT
  • SPEC
    フルチタンマフラーならではの迫力ある、抜けの良い排気音。その音量は環境に配慮し、厳しい排気音量規制をクリアしJQR認証を得ています。


    サブサイレンサー、メインサイレンサー内径は絞りのない設計とし、スポーツ走行に最適な排気効率を追求。
    ストレート構造でシングル出し、そしてチタンマフラーならではの軽量化を果たした保安基準適合マフラーとして理想のパフォーマンスを実現します。
    A powerful, iconic, and free-flowing exhaust note unique to a full titanium exhaust muffler.
    Reduced sound level for everyday driving, as well as to meet increasingly strict noise regulations even on today’s tracks.
    Optimized flow achieved by the straight-through, non-restricted inner diameter structure.
    Significant weight reduction from the single out design made by high quality titanium delivers next level of performance on the street.
    Ti SPORTS STD (M/T)
    材質MATERIAL チタニウムTITANIUM スチールIRON
    メインパイプ径MAIN PIPE DIAMETER Φ70 φ53-φ60-φ60W
    サブサイレンサー径SUB SILENCER DIAMETER 異形VARIANT 異形VARIANT
    メインサイレンサー径MAIN SILENCER DIAMETER Φ130 オーバルOVAL
    メインパイプ厚MAIN PIPE THICKNESS 1mm 1.5mm
    出口径EXIT DIAMETER Φ112 φ110二重管W110mm dual
    フランジ厚FLANGE THICKNESS プレスフランジ t=2.0mmPRESSED FLANGE t=2.0mm 2.0mm
    近接排気騒音dB:@ 3,500RPM
    MT
    AT
    85.4dB
    95dB 94dB
    加速走行騒音dB:@ Acceleration from 50km/h 82dB 82dB  –
    重量WEIGHT 8.7kg 16.3kg
    JQR認証の基準をクリア Meets the street regulation
    型押しのTOMEIロゴと事前認証制度適合の証であるJQR認証プレートをサイレンサー下側に配し、Ti SPORTSマフラーの品質を視覚的にアピール。また、レゾネーターを採用することで上質な音質と排気効率を落とすことなく音量を抑制し、スポーツ走行だけでなく、公道で使用するにあたっても安心の保安基準適合タイプです。 Pressed TOMEI logo on the main muffler.
    The JQR certificate plate also on the muffler is to prove it’s certified and meets the Japan’s street regulation.
    The external resonator reduces the noise level while keeping the straight-flow structure to suit wide usage from sport to everyday driving on the street.
    スタイルSTYLE

    大口径テールエンドBig mouth end tip

    砲弾タイプのメインサイレンサーを採用。
    大口径テールエンドはバフ処理と鮮やかなチタンブルーを施し、TOMEIロゴがデザインされています。
    Aggressive and dynamic appearance of the big mouth tail end features a buffed finish and a vivid titanium blue color, with the TOMEI logo incorporated into the design.




    関連製品RELATED PRODUCT

    バンパーガーニッシュBUMPER GARNISH
